The Kramer VP-211K 2×1 Computer Graphics Standby Switcher (VP-211K) from DJDeals.com is a high-performance switcher for computer graphics video signals, with resolutions up to and exceeding UXGA, and unbalanced stereo audio signals. When configured as a standby switcher, it switches to the secondary input upon loss of the primary input.
Kramer VP-211K 2×1 Computer Graphics Standby Switcher Features:
- High Bandwidth-300MHz (-3dB).
- Looping Input-Input 1.
- Automatic Standby Switching-Switches from secondary input to primary input when a signal is detected.
- Control-Automatic or contact closure.
- Kr-isp Advanced Sync Processing-Ensures compatibility with a wide range of computers (even if the sync level is too low) by restoring the sync signal waveform. Kr-isp advanced sync processing can be enabled or disabled.
- Primary Input-Selectable.
- Active Input LED Indicators.
- Compact Kramer TOOLSâ„¢-3 units can be rack mounted side-by-side in a 1U rack space with the optional RK-3TR rack adapter.
Kramer VP-211K 2×1 Computer Graphics Standby Switcher Specifications:
Kramer VP-211K 2×1 Computer Graphics Standby Switcher Features:
- INPUTS: 2 computer graphics video on 15-pin HD connectors;
- 2 unbalanced stereo audio on 3.5mm mini audio connectors.
- OUTPUTS: 1 computer graphics video on a 15-pin HD connector;
- 1 computer graphics video on a 15-pin HD connector (input #1 active loop);
- 1 unbalanced stereo audio on a 3.5mm mini audio connector.
- MAX. OUTPUT LEVEL: Video: 1.6Vpp; Audio: >10.5Vpp.
- BANDWIDTH (-3dB): Video: 300MHz; Audio: >100kHz.
- DIFF. GAIN: 0.03%.
- DIFF. PHASE: 0.03Deg.
- K-FACTOR: <0.05%.
- S/N RATIO: Video: 71dB; Audio: 71dB weighted.
- CROSSTALK: Video: -59dB @5MHz; Audio: <-66dB @1kHz.
- CONTROLS: Contact closure remote control, input default selection switch.
- COUPLING: DC.
- AUDIO THD + NOISE: <0.032%.
- AUDIO 2nd HARMONIC: <0.004%.
- POWER SOURCE: 5V DC 200mA.
- DIMENSIONS: 12.1cm x7.18cm x2.42cm (4.76″ x2.83″ x0.95″) W, D, H.
- WEIGHT: 0.3kg (0.66lbs) approx.
- ACCESSORIES: Power supply (5V/2.6A), mounting bracket.
- OPTIONS: 19″ rack adapters.
