The Shure UA700 Active Directional Log-Periodic Antenna (UA700-V) from DJDeals.com is a remote active antenna for compatible Shure UHF wireless systems operating in the 470-530 MHz frequency range. Its directional log-periodic design focuses reception in front of the antenna, rejecting RF interference arriving from off-axis directions, while the built-in active amplification compensates for cable loss in remote antenna installations. For productions where receivers are located at front-of-house or in a rack room far from the performance area, the UA700 provides the signal quality needed to maintain reliable dropout-free wireless performance.
Shure UA700 Active Directional Log-Periodic Antenna (UA700-V) Features:
- Directional Log-Periodic Design. The log-periodic antenna pattern concentrates reception in the forward direction, reducing sensitivity to RF interference arriving from the sides and rear of the antenna. This directional characteristic is particularly effective in high-RF environments such as arenas, convention centers, and multi-channel broadcast facilities.
- Active Amplification. An integrated low-noise amplifier boosts the received signal to compensate for coaxial cable attenuation in remote antenna installations, enabling the UA700 to be positioned far from the receivers without sacrificing signal strength or noise figure.
- 470-530 MHz Coverage. Designed for Shure UHF wireless systems operating within the 470-530 MHz frequency band, covering the standard UHF TV band range used by many Shure wireless systems in this frequency group.
- Remote Placement Flexibility. Connects to compatible Shure receivers via standard 50-ohm coaxial cable with BNC connectors, allowing placement at the edge of the stage, on a fly rail, or anywhere with a clear line of sight to the performance area.
Shure UA700 Active Directional Log-Periodic Antenna (UA700-V) Specifications:
- Model: UA700-V
- Antenna Type: Active Log-Periodic
- Frequency Range: 470-530 MHz
- Connector: BNC
