The Obsidian Control Systems Netron EN6 IP Art-Net & sACN to DMX Gateway IP66 (NIP013) from DJDeals.com is a powerful 6-port Ethernet to DMX gateway in a rugged IP66-rated powder-coated aluminum chassis. Designed for live productions, movie sets, and temporary or permanent outdoor installations — fully protected against humidity, dust, and debris. PoE or AC mains powered with locking IP66 connectors throughout. The EN6 IP unlocks a 4-universe ONYX NOVA license.
Obsidian Control Systems Netron EN6 IP Art-Net & sACN to DMX Gateway IP66 (NIP013) Features:
- IP66 Rated Chassis. Fully sealed powder-coated aluminum chassis rated IP66 for dust and high-pressure water protection in outdoor environments.
- 6 Bidirectional DMX/RDM Ports. Six IP66 5-pin XLR DMX/RDM optically isolated ports (side-mounted) — bidirectional for DMX In or Output.
- IP66 Locking Connectors. All data and power connectors feature IP66 locking XLR or RJ45 for weatherproof connections.
- RDM, Art-Net & sACN Support. Full protocol support: RDM E1.20, sACN E1.31, and Art-Net.
- 99 Internal Cues. Standalone 99-cue system with fade and delay times for scene playback without network or console.
- PoE or AC Mains Powered. Dual power input (AC 100–240V or PoE 802.3af) with IP66 locking power In/Thru connectors.
- Waterproof OLED Display & Touch Buttons. 1.8″ OLED display with waterproof touch buttons for on-device configuration in any weather condition.
- Flexible Mounting. Standalone, M10/M12 truss-mount, or wall-mount with included hardware.
- Unlocks ONYX NOVA 4 Universe License. Activation for the ONYX NOVA 4-universe license included.
Obsidian Control Systems Netron EN6 IP Art-Net & sACN to DMX Gateway IP66 (NIP013) Specifications:
- DMX Ports: 6x 5-pin IP66 XLR DMX/RDM; optically isolated; bidirectional
- Network: 2x Locking IP66 RJ45 Gigabit Ethernet (1x PoE)
- Power: IP66 Locking Power In/Thru; AC 100–240V 50/60 Hz; PoE 802.3af; 6W
- IP Rating: IP66
- Mounting: Standalone; M10/M12 truss; wall-mount (brackets included)
- Dimensions: 180mm L x 242mm W x 82mm H (7.1 in. x 9.5 in. x 3.2 in.)
- Weight: 1.8 kg (4.0 lbs.)
- Approvals: cETLus / CE / UKCA / IP66
- UPC: 810008264249
