The Datavideo DAC-70 VGA/HDMI/3G/HD/SD Cross-Converter (DAC-70) from DJDeals.com is an up/down cross-converter that converts between SD, HD, and 3G formats. It accepts VGA, SDI, and HDMI video inputs. Datavideo DAC-70 VGA/HDMI/3G/HD/SD Cross-Converter automatically converts to the selected output format, even when the video input changes. The DAC-70 is compatible with 3GB/s SDI, and the converter includes a built-in mini-USB connection for updating to support future video formats.
Datavideo DAC-70 VGA/HDMI/3G/HD/SD Cross-Converter Features:
- Cross-Conversion: DAC-70 can up-convert and down-convert between many 3G, HD, and SD video formats.
- 10-bit: DAC-70 supports 10-bit processing with high-quality video filtering.
- Low SDI Jitter: DAC-70 is built with high-quality standards for low SDI jitter with long SDI cable lengths.
- Multi-Channel Audio: Multi-channel audio is supported (Up to 8 Channels embedded)
- Firmware Upgradable: The firmware is upgradable via the DAC-70’s mini-USB port.
- RMK-2 Compatible: DAC-70 is compatible with the RMK-2 holder, for holding multiple converters and distribution amplifiers in a 2RU space.
Datavideo DAC-70 VGA/HDMI/3G/HD/SD Cross-Converter Specifications:
- Supported Input Formats
- 3G-SDI: 1080p (50/59.94/60)
- HD-SDI: 1080p (23.98/24/25/29.97/30)
- HD-SDI: 1080i (50/59.94/60)
- HD-SDI: 720p (50/59.94/60)
- SD-SDI: 525i, 625i
- HDMI: 1080p (23.98/24/25/29.97/30/50/59.94/60)
- HDMI: 1080i (50/59.94/60)
- HDMI: 720p (50/59.94/60)
- HDMI: 480p, 576p
- HDMI: 800×600@60Hz, 1024×768@60Hz,1280×1024@60Hz 1366×768@60Hz, 1400×1050@60Hz, 1600×1200@60Hz
- VGA: 800×600@60Hz, 1024×768@60Hz,1280×1024@60Hz, 1366×768@60Hz, 1400×1050@60Hz, 1600×1200@60Hz
- *HDMI supports YUV/RGB color spaceSupported Output Formats
- SDI/HDMI: 1080p (23.98/24/25/29.97/30/50/59.94/60)
- SDI/HDMI: 1080i (50/59.94/60)
- SDI/HDMI: 720p (50/59.94/60)
- SDI/HDMI: 525i, 625iAudio Support
- Input- Analog Audio L/R: Stereo
- Input- SDI embedded audio up to 8CH, 48KHz, PCM audio
- Input- HDMI embedded audio up to 8CH, 44.1/48/96KHz, PCM audio
- Output- SDI/HDMI embedded audio up to 8CH, 48KHz, PCM audioInputs
- 1x VGA
- 1x HDMI
- 1x 3G/HD/SD-SDI
- 1x Analog Audio Left/Right PairOutputs
- 2x 3G/HD/SD-SDI
- 1x HDMI
- 1x 3G/HD/SD-SDI Loop-Through
Datavideo DAC-70 VGA/HDMI/3G/HD/SD Cross-Converter Includes:
- DAC-70 Unit
- Instruction Manual
- Power Supply and Cord (12V/1.0A)
