ADJ VS3 3.91mm Pixel Pitch Indoor LED Video Wall Panel

ADJ VS3 3.91mm Pixel Pitch Indoor LED Video Wall Panel - Image 2

ADJ VS3 3.91mm Pixel Pitch Indoor LED Video Wall Panel - Image 3

ADJ VS3 3.91mm Pixel Pitch Indoor LED Video Wall Panel - Image 4

ADJ VS3 3.91mm Pixel Pitch Indoor LED Video Wall Panel

Name: ADJ VS3 3.91mm Pixel Pitch Indoor LED Video Wall Panel
Brand: American DJ
SKU: 38596
Price: 1262.50 USD
Availability: InStock
Rating: 5 (1 reviews)

0 reviews | 0 questions

$1,328.95Add to Cart to Save 5% on this Product!

The ADJ VS3 3.91mm Pixel Pitch Indoor LED Video Wall Panel from DJDeals.com is a high-resolution video panel with a pixel pitch of 3.91mm with a configuration of a 3-in-1 RGB SMD2121 LED, and a brightness of 1000 NITS. There are 4 LED modules per ADJ VS3 3.91mm Pixel Pitch LED Video Wall Panel. This allows for easy serviceability. The ADJ VS3 3.91mm Pixel Pitch Indoor LED Video Wall Panel connections include PowerLock In/Out and DataLock In/Out. Each panel features the Novastar A5s receiving card built-in. Up to 8 VS3 video panels fit inside the VSFC8 flight case. Hang up to 20 VS Series Video Panels vertically with the VSRB1 rigging bar.

Authorized American DJ Dealer

UPC: 818651027990 Category: LED Video Wall Systems

The ADJ VS3 3.91mm Pixel Pitch Indoor LED Video Wall Panel from DJDeals.com offer the highest quality LED binning and bright, clear output. All models are front and rear serviceable. Each model has 4 individual mini modules for quick and easy servicing. All models are built on the same frame allowing panels with different resolutions to be used together. The Vision Series panels use the same rigging bar and all fit into the same road case. All models have moveable corner protects that safe guard the corners while they are not connected. There are magnets on the top and bottom of the panels that allow users to temporary connect two panels together, let go of the panels, then securely latch them on the rear. This allows for a single user to install a full wall of panels.

The ADJ VS3 3.91mm Pixel Pitch LED Video Wall Panel is a high-resolution video panel with a pixel pitch of 3.91mm with a configuration of a 3-in-1 RGB SMD2121 LED, and a brightness of 1000 NITS. There are 4 LED modules per ADJ VS3 3.91mm Pixel Pitch LED Video Wall Panel. This allows for easy serviceability. The ADJ VS3 3.91mm Pixel Pitch LED Video Wall Panel connections include PowerLock In/Out and DataLock In/Out. Each panel features the Novastar A5s receiving card built-in. Up to 8 VS3 video panels fit inside the VSFC8 flight case. Hang up to 20 VS Series Video Panels vertically with the ADJ VSRB1 Single Panel Rigging Bar for Vision Series LED Video Wall Panels.

ADJ VS3 3.91mm Pixel Pitch Indoor LED Video Wall Panel Features:

Corner Protectors to protect the corners of the VS3 during transport, set-up and teardown.
Front and rear serviceable.
4 easy to replace video modules on each panel.

ADJ VS3 3.91mm 168×168 Indoor LED Video Wall Panel Specifications:

• Pixel Pitch: 3.91mm (0.15”)
• LED Configuration: 3-in-1 SMD2121 LED
• Pixel Density: 128×128; 65536 per square meter
• Size :19.68” x19.68” x2.75”/500 x500 x69.6mm
• Module Quantity: 4
• Weight: 17 lbs./7.7kg.

FEATURES:

• Corner Protectors to protect the corners of the VS3 during transport, set-up and teardown
• Front and rear serviceable: 4 easy to replace video modules on each panel
• Magnets on top/bottom to temporarily connect panels before latching together allowing a single user to install an entire wall

MECHANICAL RATINGS:

• Surface Flatness: Gaps<0.5mm

OPTICAL RATINGS:

• Brightness: 1000 NITS
• View Angle: Horizontal 160°/Vertical 140° @ 9.75 ft. (3m)
• Gray Scale: ≥14-bit
• Display Color: 256
• Brightness Adjustment: 0~100% 100 Levels• Contrast ratio: 5000:1• Processing: 14-bit

POWER SUPPLY:

• Operation Power: 100~240V 50-60Hz
• Max. Power Consumption: 170W/per panel
• Ave. Power Consumption: 68W/per panel
• Connections Power/Data: Power-PowerLock In/Out; DataLock In/Out

CONTROL SYSTEM:

• Control Mode: Nova Star Synchronous System with Control via DVI
• Frame Update Frequency: 50-75Hz
• Scan Mode: 1/16
• Refresh Rate: 3840Hz
• Support Input: Composite, S-Video, Component, VGA, DVI, HDMI, HD_SDI
• Control Distance: Ethernet Cable <120m or Fiber Optic>120m
• Support VGA Mode: 1024 x768, 1280 x1024, 1600 x1200, 1920 x1280
• Brightness Correction: Pixel, Module, Cabinet

ENVIRONMENTAL:

• Operating Temp/Humidity: Fahrenheit: -4° + 104°/Celsius: -20° + 40°/ 10-90% (No Condensation)• Operating Life/MTBF: 50,000 Hours/5,000 Hours
• Protection Level: IP20 (Front and Back)
• Out of Control Rate: <0.02%
• Listings: cETLus (Pending)

OPTIONAL ACCESSORIES:

• VSFC8 (VS8100): Flight Case Fits 8 VS Series Video Panels
• VSRB1 (VS1100): Rigging Bar Hang up to 20 VS Series Video Panels vertically
• VSMRT (VSM111): Module Removal tool-Magnetically assists the tech in removing modules from the front side when servicing.
• VSRQR (VSM210): Quick Rig-Attaches and locks on to the rear of any Vision series panel so it can be fastened to a 2″ pipe or truss
• Novastar VX4S: Video Processor
• Novastar MCTRL-300: Video Processor
• Novastar Nova Pro HD: Video Processor
• Arkaos Media Master: Video Software
• Arkaos GrandVJ 2.0: Video Software

CABLES:

• Cabinet to Cabinet Data Link Cables (Ethernet Locking Connectors)
• Power Locking Link Cables
• Power Locking Main Power Cables

Weight	20 lbs
Dimensions	22 × 22 × 5 in
