The ADJ/Elation DP-DMX20L DMX Dimmer Pack (DP-DMX20L) from DJDeals.com is a 4 channel universal, portable DMX dimmer/switch pack. That has a selectable 1,2 or 4 channel operation. With dual 3-prong Edison sockets per channel, allowing you to hook up two devices per channel. The ADJ DP-DMX20L has 4 LED’s display for channel activity.
There are dual Edison sockets on the ADJ DP-DMX20L DMX Dimmer Pack so more than one effect can be connected to each channel. There are 16 built in chase sequences, with speed and intensity control, available for your convenience. ADJ DP-DMX20L DMX Dimmer Pack also has four external channel fuses which allows for quick and easy serviceability while out on the road.
ADJ DP-DMX20L has a sleek reversible mounting panel on the rear to make it easier to install, and a zero crossing circuitry for protection of the transformer loads when switching.
ADJ DP-DMX20L DMX Dimmer Pack Specifications:
• 4 channel DMX Dimmer Pack
• Digital display- used to set starting DMX address channels and set all other menu options
• Selectable 1, 2, or 4 channel operation
• Adjustable master dim level.
• Two three prong Edison sockets per channel
• 3 pin XLR DMX Input & Output
• Four LEDs display channel activity
• External channel fuses for quick and easy replacement
• Sleek reversible mounting panel on the rear
• Zero crossing circuitry for protection of transformer loads when switching
• 16 built in Chases when in Chase mode with adjustable speed setting
• Use in conjunction with Elation Professional; DMX Operator Pro, Stage Setter-8, Scene
• Reversible mounting brackets.
• Setter, Scene Setter-48, Stage Desk-16 or any universal DMX lighting controller
• Power Input: 120V ~ 60Hz
• Maximum Load: 10A per channel/20A total
• Dimensions: 10.25”L x8.25”W x3”H
• Weight: 6 lbs
